SP 1B 04 Phoenix Single Convolution Air Spring AIRSUSTECH 1B4060 with Metal Plate

Material : Steel and Rubber

Port Size : G1/8

Full Stroke : 60 MM

Model No. : Contitech FS 40-6

Color : Black

Maintenance : Low

Advantage : Serviceable

Manufacturer Warranty : One Year

Brand Name : AIRSUSTECH

Model Number : 1B4060

Certification : ISO/TS16949:2009

Place of Origin : Guangzhou, China

MOQ : 1 Piece

Price : Negotiable

Payment Terms : T/T,,Paypal or Others,L/C,D/A,D/P,MoneyGram

Supply Ability : 1000 PCS/Week

Delivery Time : 3-8 Working Days

Packaging Details : Strong Carton Box or as Customers Requirement

Contact Now

SP 1B 04 Phoenix Single Convolution Air Spring AIRSUSTECH 1B4060 with Metal Plate
Product Overview

This single bellows pneumatic actuator is constructed from high-grade natural rubber and steel mounting plates, designed for industrial vibration isolation applications.

Key Features
  • Constructed from high-grade natural rubber and steel mounting plates
  • Minimum compressed height: 50 mm, maximum extended height: 110 mm, functional stroke: 60 mm
  • Mounting plate diameter: 90 mm with center-to-center distance of 20 mm
  • Maximum outer diameter at 0.7 MPa operating pressure: 145 mm
  • Operates through gas inflation with G1/8 air connection
  • Installation via M8×1.25 threaded holes
Cross Reference Part Numbers
AIRSUSTECH

Part No.: 1B4060

Phoenix

Part No.: SP 1B 04, SP 1B04, SP1B04

Contitech

Part No.: FS 40-6, FS 40 6, FS 406, FS 40-6 M8, FS 40-6 G1/8, FS 40-6 M8 G1/8

Weforma

Part No.: WBE 100-E1, WBE 100 E1, WBE 100E1, WBE100-E1, WBE100 E1, WBE100E1

Technical Specifications
Vibration Isolation - Dynamic Characteristics
Pressure P [bar] 3 4 5 6 7 8 Vol. V[l]
Force (Load) [kN] 1.7 2.3 2.8 3.4 3.8 4.4 0.5
Spring Rate [N/cm] 760 990 1220 1480 1610 1820
Natural Frequency [Hz] 3.5 3.3 3.3 3.3 3.2 3.2
Pneumatic Application - Static Characteristics
Pressure p [bar] 3 4 5 6 7 8 Vol.[l]
Height H [mm] 100 1.2 1.6 2.0 2.5 3.0 3.4 0.6
Height H [mm] 90 1.7 2.2 2.8 3.4 3.9 4.4 0.5
Height H [mm] 80 2.1 2.8 3.5 4.2 4.9 5.3 0.5
Height H [mm] 70 2.3 3.2 3.9 4.7 5.4 6.2 0.4
Height H [mm] 60 2.6 3.5 4.3 5.2 6.1 6.9 0.3
Procurement Process
1. OEM Part Identification

Provide original manufacturer part numbers for required air springs

2. Technical Validation

We verify specifications against OEM drawings to ensure exact compatibility

3. Quotation Request

Submit required quantities, company information, and equipment application details. Receive customized pricing within 24 hours.

4. Logistics Coordination

Provide complete delivery address + postal code. We calculate freight costs across all carriers.

5. Order Confirmation

Receive proforma invoice with itemized product costs, shipping cost, and payment terms.

6. Manufacturing Initiation

Production commences within 24 hours of signed PO acceptance and payment clearance.

7. Global Shipping & Tracking

Includes Airway Bill (AWB) number, real-time tracking portal access, and commercial invoice copies.

Product Images
SP 1B 04 Phoenix Single Convolution Air Spring AIRSUSTECH 1B4060 with Metal Plate SP 1B 04 Phoenix Single Convolution Air Spring AIRSUSTECH 1B4060 with Metal Plate SP 1B 04 Phoenix Single Convolution Air Spring AIRSUSTECH 1B4060 with Metal Plate SP 1B 04 Phoenix Single Convolution Air Spring AIRSUSTECH 1B4060 with Metal Plate
